Power adaptor for cctv microphone DC12V
GO Back- SKU: SUPR-211
- Brand: silver
- Color: white
- Weight: 315g
- Size: 103mm*65mm*40mm
- Material: metal
- MOQ: >10
- Lead time: 7-15 days
- Description
- Parameter
Specifically for audio monitoring design special pick-up power.
The power supply can be provided with a ripple clean dc 12V.
Let the pick-up output audio signal to noise smaller, reduce user due to the use of power caused by improper pickup sound big problem.
Input voltage
AC220 v
Output voltage
DC 12 v
Output current acuities
200 ma
Input
V (pick-up positive) A (pick-up signal output positive) G (public, is also the pick-up power negative and pick-up audio output negative public end)
Output interface
A 3.5 mm headphone jack, A two core terminal (A for audio signal positive, G for audio signal negative)
Volume control
the power can be directly monitoring pick-up, with the volume potentiometer, adjust signal output amplitude size, so as to control the size of the voice.
